ACD 400.1 Ex – filtration unit for atmospheres with combustible gases

Grey system on device castors for mobile extraction tasks

Product details

Application fields

  • Bonding, laminating, varnishing

  • Pre-treat, cleaning

  • Moulding, printing, and more

Features

  • Mobile extraction system with castors

  • Explosion protected ventilator compliant with ATEX EEx e II 2G

  • Filter cassettes electrically conductive with potential equalization connection

  • All electrical components in CE-compliant design

  • Controls in separate starter box

  • Simple filter handling, modular construction

  • Powder-coated, rugged steel housing

  • Low energy consumption through energy-efficient device electronics

  • To prevent the ignition of concentrated flammable gases and vapors in the filter, the activated carbon filter elements and subsequent components, such as the ATEX-compliant fan and the ATEX-compliant motor, are earthed and designed to be free of ignition sources

Technical specifications

Device versionACD 400 Ex MD.43
Max. air flow in m³/h900
Max. vacuum in Pa1650
Nominal capacity in m³/h@Pa300 @ 1000
Dimensions in mm (WxDxH)670 x 600 x 872
Weight in kg100
Noise level in dB60

System benefits

  1. Low energy consumption

    Our extraction systems reduce operating and maintenance costs due to their optimal filter concept. In addition, the system is designed in such a way that it keeps the required energy consumption extremely low.

  2. Simple operation

    Our extraction and filtration systems have been designed in such a way that they can be put into operation trouble-free and are easy to operate. They are easy to operate, handle and maintain.

  3. Based on R&D

    Research and development (R&D) has highest importance at ULT. Many projects with well-known partners and institutes have been resulted in new approaches for ventilation systems, which are often transferred to series products or quickly and easily adapted to customer-specific projects.

  4. Ideal filtration technology

    The utilization of the most sensible filtration technology ensures a long filter service life and, consequently, reduces maintenance and spare parts costs. ULT always offers You the ideal solution for your specific pollutant technology in order to achieve the best possible filtration results.

  5. High flexibility

    Our extraction and filtration systems can be used flexibly. This lets you choose, for instance, between mobile and/or stationary solutions, integrated systems, or specialized ventilation solutions. If necessary, the optimal application can be configured by ULT experts on-site.

  6. Long filter time

    The long performance life of the filter elements in our systems reduces maintenance and material costs in the medium and long term. In addition, the downtimes for necessary filter module changes or system cleaning are significantly reduced.

  7. Contamination-low filter replacement

    Thanks to our specially developed “Save Change Technology”, filter changes are extremely low-contamination. This protects operators and employees.

  8. Low-noise operation

    ULT's extraction and filtration systems are particularly quiet. This has already been appreciated by numerous customers worldwide. Your employees are thus effectively protected against noise pollution.

  9. Modular construction

    Modularity is the basis for the effective use of ULT ventilation solutions. This allows You to react flexibly to changing pollutant or processing scenarios and always exploit the full potential of the systems.

Downloads

  1. Technical documentation ACD 400.1 Ex
Images
Side view of the grey system with two wheel sizes
The filter system requires a small footprint of just 670 x 600 mm
Schematic representation of a person next to the unit
Size ratio human-machine
ACD 400.1 Ex for combustible gases and vapors
Modular design with dust pre-filter and two adsorption filter modules
Side view of the system with device castors
Device castors allow flexible use of the filter system
Front of the extraction unit with blue sticker at the bottom right
Front view of the ACD 400.1 Ex
Rear of the system with discharge grille with ULT logo
Discharge grille and system interfaces on the rear of the device
Side view of the grey system with two wheel sizes
The filter system requires a small footprint of just 670 x 600 mm
Schematic representation of a person next to the unit
Size ratio human-machine
ACD 400.1 Ex for combustible gases and vapors
Modular design with dust pre-filter and two adsorption filter modules
Side view of the system with device castors
Device castors allow flexible use of the filter system
