JUMBO Filtertrolley LabCat – mobile fume extraction in the lab

Product details

Application fields

  • Removal of dusts, hases, and vapors

  • Research tasks in medical technology, pharmaceutics, and chemistry

  • For small amounts of air contaminants and particles

  • For changing workplaces and conditions

Features

  • Uniquely designed mobile extraction and filtration unit

  • Flexible utilization for various applications

  • High suction power, steplessly adjustable

  • Extremely quiet operation

  • Simple filter handling, access via suction plate

  • Impact resistant ABS, chemical resistant, corrosion resistant

  • Installation of extraction arms (Ø 50, 63, 75) and application-specific capturing elements

System benefits

  1. Low-noise operation

    ULT's extraction and filtration systems are particularly quiet. This has already been appreciated by numerous customers worldwide. Your employees are thus effectively protected against noise pollution.

  2. High flexibility

    Many of the ULT fume extraction systems can be utilized flexibly. For example, You can choose between mobile or stationary solutions, system integrations or special ventilation solutions. If necessary, the ideal application is configured by ULT experts on-site.

  3. Low energy consumption

    Our extraction systems reduce operating and maintenance costs due to their optimal filter concept. In addition, the system is designed in such a way that it keeps the required energy consumption extremely low.

  4. Simple operation

    Our extraction and filtration systems have been designed in such a way that they can be put into operation trouble-free and are easy to operate. They are easy to operate, handle and maintain.

  5. Ideal filtration technology

    The utilization of the most sensible filtration technology ensures a long filter service life and, consequently, reduces maintenance and spare parts costs. ULT always offers You the ideal solution for your specific pollutant technology in order to achieve the best possible filtration results.

  6. Based on R&D

    Research and development (R&D) has highest importance at ULT. Many projects with well-known partners and institutes have been resulted in new approaches for ventilation systems, which are often transferred to series products or quickly and easily adapted to customer-specific projects.

Technical specifications
Device versionJUMBO Filtertrolley 2.0 LabCat
Max. air flow in m³/h190
Max. vacuum in Pa3200
Nominal capacity in m³/h@Pa80 @ 1900
Dimensions in mm (WxDxH)450x340x530
Weight in kg36
Noise level in dB49
Connection variants – diameter in mm1 X 50 / option: 1 X 75
Images
Capturing of airborne pollutants in the laboratory
Connection options for one or two extraction arms
Mobile extraction and filtration device JUMBO Filtertrolley white
Device-human size ratio
Mobile filter system for various applications
JUMBO LabCat for clean air in laboratories
JUMBO Filtertrolley LabCat
Mobile extraction device with dust, fine dust and adsorption filters
Mobile air purification device for labs
Stepless adjustment of the suction power at minimum noise level
JUMBO LabCat supports occupational health and safety
Simple filter handling and flexible suction plate with extraction arm
Capturing of airborne pollutants in the laboratory
Connection options for one or two extraction arms
Mobile extraction and filtration device JUMBO Filtertrolley white
Device-human size ratio
Mobile filter system for various applications
JUMBO LabCat for clean air in laboratories
JUMBO Filtertrolley LabCat
Mobile extraction device with dust, fine dust and adsorption filters
